Page #19 background image
19
Technical Characteristics
Channels
Output Power (RMS)
Stereo @ 4 Ohm
Stereo @ 2 Ohm
Bridged @ 4 Ohm
T.H.D.
Frequency Response
S/N Ratio
Separation @ 1 kHz
Transient Distortion (100W)
RCA Input
BY-PASS
Input Sensivity
Bass Boost
Phase Shift
HP Range
LP Range
Input Impedance
Damping factor
Max Current
@ 4 Ohm; 14,4V; 0,3% THD
@ 2 Ohm; 14,4V; 0,3% THD
Remote Volume Control
Installation and Connections
General Rules
The following shows several device types describing their connection and adjustment. These descriptions
are designed to show you in a clear form how to operate the amplifier.
This does not exclude that your dealer can individually modify and use the system. (dieser Satz ist für mich
unverstandlich)
Speaker Load
It is possible to connect systems with multiple loudspeakers as long as the total impedance is greater than 2
ohm.
PA 1502 PA 2802
2
2 x 165 W
2 x 310 W
1 x 660 W
<0,03%
20 Hz - 100 kHz
>106 dB
>72 dB
<0,01% @ 4 Ohm
YES
YES
0,2 - 4,3V
45 Hz / 0 - +12 dB
0 - 360°
16 - 160 Hz
45 - 300 Hz
11 kOhm
>1000
37 A
75 A
0 - +15 dB
2
2 x 298 W
2 x 560 W
1 x 1192 W
<0,03%
20 Hz - 100 kHz
>106 dB
<0,01% @ 4 Ohm
YES
YES
0,2 - 4,3V
45 Hz / 0 - +12 dB
0 - 360°
16 - 160 Hz
45 - 300 Hz
11 kOhm
>1000
67 A
141 A
0 - +15 dB
