Eton PA1102 User Manual

PA 3204
GESAMT STEREO STANDARDKONFIGURATION
TYPICAL FULL RANGE STEREO CONFIGURATION
ZUM GESCHALTETEN
+12V (ZÜNDSCHLOSS)
ODER AUTORADIO-
ANTENNENANSCHLUSS +12V
TO TURN - ON
(REMOTE) OF DECK
10
EINSTELLUNG/SET TO
FULL
EINSTELLUNG/SET TO
STEREO
VORN/FRONT
2 OHM MIN.
PRO KANAL/
PER CHANNEL
HINTEN/REAR
2 OHM MIN.
PRO KANAL/
PER CHANNEL
BASS
BOOST
0 18
dB
X 10
X 1
FREQ
RANGE
FREQ Hz
50
65
550
200
95
FREQ Hz
50
65
550
200
95
POWER
FRONT
GAIN
FRONT
(2 CH. IN)
REAR
REAR
GAIN
L
R
INPUT
FRONT
FRONT
L & R SUM MONO
L & R SUM MONO
STEREO
STEREO
BRIDGED (F R IN)
(F L IN) BRIDGED
REAR
REAR
SELECT
SOURCE
2 CH.
W/BASS
4 CH.
2 CH.
FULL LOW
HIGH
FULL LOW
HIGH
40
AMP MAX
+12VGND
TURN
ON
REAR
FRONT
L R
MIN
2
BRIDGED
MIN
4
2
MIN
ZUR BATTERIE +POL
MIT SICHERUNG AN BATTERIE
FÜR KABELKURZSCHLUSSSCHUTZ
5 mm² KABEL
TO BATTERY +12V
FUSE AT BATTERY
FOR WIRE SHORT PROTECTION
5 mm² (AWG 10) WIRE
MASSE AN CHASSIS
KABELLÄNGE MAXIMAL 45 cm
5 mm² KABEL
GROUND TO CHASSIS
WIRE LENGTH - 18 INCH MAX
5 mm² (AWG 10) WIRE
