ETQ 170F - Page 11

1-2.2 Crankshaft driving angles must be less than 120
o
, see Fig 1-1
The tilt must be kept within the allowed values shown in Fig 1-2
Fig 1-1. Allowed driving angles. Fig 1-2. Allowed tilt angles.
Model Units: (amp-hours)
170F 18~24
178F 24~26
186F
1-2.3 Please contact our dealers about the electric circuits involved with this engine.
We recommend the use of accumulators rated at 20 hours shown in table 1-2.
Table 1-2.
36~45
11
