09
Chain Tension adjustment:
a. Use an M9 wrench to loosen the chain tensioner nuts.
b. Use an M10 wrench to adjust the chain tension as shown in the picture.
Chain Play: The chain should be able to move 1/4 to 1/2 inch in both directions.
6. Seat Installation
1. Disengage the seat post lock.
2. Insert the seat post into the frame of the e-bike.
3. Adjust the seat to the desired height and tighten the seat
post lock.
NOTE: Do not exceed the seat height limit marked with a line on
the seat post to avoid accidents and or damage to the e-bike.
