The tension-relief strap may not cover the third braking light.
The tension-relief strap may not in uence the functionality of the
rear windscreen wipers.
Now attach the lock section of the strap to the U-bar as shown on Figures 7 to 10.
Figure 7
Figure 11 Figure 12 Figure 13
Figure 8 Figure 9 Figure 10
Connect both parts of the tension-relief strap as shown on Figures 11 to 13.
Now pull the tension-relief strap tight.
Make sure that any roof edge spoilers are not damaged and that the functionality of the tension-relief strap is not in-
uenced by such spoilers.
Figure 14: Tension-relief strap
In order to release the tension-relief strap, press the lock down (Figure 6, Position 1) and pull the strap out of the lock.
Tension-relief strap
6. MAINTENANCE AND CARE
• After use, store the bicycle rack in a clean and dry place. Wash any mud or other dirt o using water.
• Keep the trailer tow bar clean and free of grease
• Keep the rack tow bar clean and free of grease.
• Check the bicycle rack regularly for damages. Damaged or worn parts must be replaced immediately. Only original replacement parts may be used.
• Check the bolts and nuts of the bicycle rack regularly and tighten when necessary.
• Immediately treat any damage to paintwork with paint.
• Regularly lubricate rotating and moving parts.
7. NOTES REGARDING ENVIRONMENTAL PROTECTION
Please dispose of this device via the recycling bin or the public/municipal collection points.
The materials are recyclable. You make an important contribution to protecting our environment by recycling, material utilisation or other
forms of reusing waste equipment!
