Please read the operating instructions carefully prior to use and observe all safety instructions!
Not observing such may lead to personal injury, damage to the device or to your property!
Store the original packaging, the receipt and these instructions so that they may be consulted at a later date! When
passing on the product, please include these operating instructions as well.
Please check the contents of package for integrity and completeness prior to use!
WARNING
1. PROPER USE OF THE PRODUCT
This extension element is designed only for use with the EUFAB bicycle rack JAMES item number: 11417 and is used to extend the carrying capacity of the
rack from two to three bicycles.
This product is not designed to be used by children or persons with limited mental abilities or without experience and/or lack of required specialist
knowledge. Children should be kept away.
The product is not designated for commercial use.
Utilisation according to the intended purpose also includes the observance of all information in these operating instructions, particularly the observance
of the safety instructions. Any other use is considered improper and can lead to property damage or personal injury. EAL GmbH assumes no liability for
damage resulting from improper use.
2. SCOPE OF DELIVERY
3. SPECIFICATIONS
Observe the speci cations in the assembly instructions of the bicycle rack. The maximum payload of the bicycle rack and the permitted support load of the
tow bar coupling may not be exceeded.
The permitted overall weight, as well as the permitted axle load of the vehicle may not be exceeded by the bicycle rack and its load.
2 x Wheel rail half
2 x Base frame extension
1 x Rail connector
1 x Connection element
1 x Metal tongue
2 x Wheel stop
Extension element for 3rd bicycle for 11417 JAMES
4. SAFETY PRECAUTIONS
WARNING!
The instructions contain the following categories of safety precaution:
Personal injury possible:
Notes with the word WARNING! warn of a potential risk. If this is not prevented, death or serious injury may be the consequence.
3 x Tensioning strap, small
1 x Tension-relief strap
1 x Strap guide
2 x Link screw M6 x 75
4 x Allen screw M6 x 15
4 x Plastic wing nut
6 x Washer 18 x 6 x 1
2 x Washer 12 x 6 x 1
1 x Allen key 5 mm
1 x Frame holder „Wheel to Wheel“, with 2 keys
Cable tie
Assembly instructions
1. PROPER USE OF THE PRODUCT 9
2. SCOPE OF DELIVERY 9
3. SPECIFICATIONS 9
4. SAFETY PRECAUTIONS 9
5. INSTRUCTIONS FOR USE 11
5.1 ASSEMBLY OF THE 3RD WHEEL RAIL 11
5.2 LAYING THE ELECTRICAL CABLE 13
5.3 SECURING THE THIRD BICYCLE 13
5.4 SECURING THE TENSIONRELIEF STRAP 13
6. MAINTENANCE AND CARE 14
7. NOTES REGARDING ENVIRONMENTAL PROTECTION 14
8. CONTACT INFORMATION 14
ATTENTION!
Personal injury or property damages are possible:
Notes with the word ATTENTION! warn of a potential risk. If this is not prevented, minor or slight injury may be the consequence. The
product or something in the vicinity may be badly damaged.
Weight: Approximately 3.5 kg Length of rail: Approximately 140 cm
