EUFAB 11577 - Scope of Delivery; Specifications; Safety Precautions; Operating Instructions

6
2. Scope of delivery
3. Specications
1 x Frame holder with two keys
1 x Operating instructions
Item
number
Length
U-shaped bracket
diameter
Bicycle frame diameter
Weight
11575
12 cm
25 mm
Maximum 80 mm
0.350 kg
11576
32 cm
25 mm
Maximum 80 mm
0.450 kg
11577
12 cm
30 mm
Maximum 80 mm
0.350 kg
11578
32 cm
30 mm
Maximum 80 mm
0.450 kg
11579
15 cm
---
Maximum 80 mm
0.400 kg
4. Safety precautions
• The warning triangle indicates all instructions which are important for safety.
Always follow these otherwise you could injure yourself or damage the device.
• Children may not play with the device.
• Cleaning and user maintenance may not be carried out by children without
supervision.
• Do not treat packaging material carelessly. This may become a dangerous playt-
hing for a child!
• Only use this product for its designated purpose!
• Do not manipulate or disassemble the frame mount!
• For your own safety, only use accessories and spare parts that are stated in these
instructions or that are recommended by the manufacturer!
• If the frame holder is visibly damaged, safe use is no longer possible. The frame
holder may thus no longer be used.
• Observe the specications and safety precautions in the instructions for your
bicycle rack!
5. Operating instructions
5.1 Overview
Figure 1: Overview
1 U shaped bracket cu
2 Lock
3 Locking and release lever
4 Strap
5 Frame protector
6 Key
