Step 3 Install Exterior Assembly
1. If the cross bore diameter of your door is 38 mm, remove the spacer before installation.
Cross Bore
Diameter
1 ½ in / 38 mm
2. Make sure the cable goes underneath the deadbolt.
Step 4 Install Interior Assembly
1. Detach the mounting plate and battery cover from the interior assembly.
Set
2. Run the cables through the slot on the mounting plate. Make sure the silicone pad is against the door.
