3. Attach the side with the silicone pad to the door, and secure the mounting plate with screws.
E
Tightly fasten the screws in
place. Set the screws with
your hands, then use a
screwdriver to secure them.
4. Plug the power cable into the sockets on the back of the interior assembly.
Route the cables around the tailpiece receiver to avoid pinching during installation.
5. Insert the T-shaped tailpiece of the exterior keypad into the T-shaped tailpiece receiver of the interior assembly.
Make sure the wire is tucked into the cavity on the back of the interior assembly.
F G
Set
Set
Make sure the deadbolt is
retracted and the thumbturn
knob is on the 'unlock' position,
check if the deadbolt moves
properly by turning the
thumbturn.
Use a long screwdriver
to fasten the interior
assembly screws. Insert the
silicone plug into the hole
below the thumbturn.
