Euphonix Max Air Contro
l Surface Manual
19
User Reference
Internal Components
Figure 14
CM404
Figure 15
CM416
Dual Power
Connections
Dual Power
Supplies
KVM Extender
Power
Distribution
Single Board
Computer
Dual Power
Connections
Dual Power
Supplies
Single Board
Computer
Power
Distribution
18
20
