How to maintain your robot
▪ Cleaning brush
Turn the main unit over. Release the cover plate of the
main brush and pull it out, and lift the right side of the
main brush to take it out.
01
Clean the main brush
and its cover plate with
the cleaning brush or a
soft cloth.
02
After cleaning, press the end cover back to the main
brush body. Install the main brush body into the main
unit according to the direction shown in the figure. It is
recommended to clean the main brush every week and
replace them every 6 months.
04
Rinse the main brush
and dry it before
putting it back.
03
▪ Main brush maintenance (weekly cleaning recommended)
CAUTION
Make sure robot is turned off and not plugged
into a power source.
WARNING
Do not attempt to remove belt.
How to use the cleaning brush:
1. Cut the hair entangled on the main brush with the blade.
2. Bush off the hair.
Brush
Blade
Washable brushroll – clean frequently
