19
Other routine maintenance
▪ Main wheels cleaning (weekly cleaning recommended)
▪ Side brushes cleaning (weekly cleaning recommended)
Rotate the main wheels back and forth to remove debris or dust
- remove and take out the hair or debris with the cleaning brush
or a soft cloth.
Pull out the side brush.
Remove dust on the
side brush.
01
It is recommended to
clean the side brush
every week and
replace them every
6 months.
02
▪ How to empty the dust cup
Flip the slide switch
to the left so that
the dust cup is
detachable.
01
Flip the slide switch to
the right to lock the
dust cup.
05
Main wheels and side brushes cleaning
Maintenance of Self-Emptying Base
Empty as soon as dirt
reaches the MAX mark.
Remove the dust cup
by moving it vertically
upwards.
02
Close the tab, and place
the dust cup straight
down back into the
self-emptying base.
04
Hold the dust cup over
a bin. Press the lower
dust cup release tab
and empty the trash
into the bin.
03
