EuroLite Color Chief User Manual

33
•
EN
TECHNICAL SPECIFICATIONS
Power supply:
100
-
240 V AC, 50/60 Hz via included
power adapter (9 V/800 mA)
Power consumption:
<10 W
Control channels:
maximum 240
Storable scenes/chase
s:
24
DMX512 output:
3
-
pin XLR connector
Sound control:
via built
-
in microphone or RCA line input (min. 100 mV)
Available storage media:
USB
devices (FAT32)
Dimensions (L x W x H):
482 x 132 x 85 mm
Rack installation with 3 U
Weight:
2.2 kg
Specifications are subject to change without notice due to product improvements.
Pin connection:

EuroLite Color Chief Specifications

General

Type	DMX Controller
MIDI	Yes
USB	No
DMX output connector	3-pin XLR
Display	LCD
Power supply	12V DC
