00117370, Version 1.0
20/24
15k 15000 Hz
20k 20000 Hz
25k 25000 Hz
Gamma settings
gAmm
no 0
2.0 2.0
2.2
2.2
2.4 2.4
2.6 2.6
2.8
2.8
Manual mode
nAnu 0-255 Brightness 0-100%
Behavior in case of
missing DMX signal
Lost
Hold Most recent DMX value is held
Blackout LEDs switched off
Temperature
temp xx Internal temperature
Display deactivation
LEd
On Deactivation after 20 seconds
oFF Display always active
Display reverse
dISP
On Display reversed
oFF Display normal
Working hours
FhrS xx Total working hours
Software version
ver xx Current software version
Default
deFA Reset to default settings
DMX operation
Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 3 control channels.
However, it can also be switched to a mode with 1 or 2 channels if different functions are required. To be
able to operate the device with a DMX controller, the DMX starting address must be set for the first DMX
channel. The starting address depends upon which DMX controller is being used. Please refer to the
controller’s documentation.
1 Press the MENU button so many times until Addr is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired DMX address. Confirm with the ENTER
button again.
2 Press the MENU button so many times until Chnd is indicated in the display. The display indicates 1 CH
(1 DMX channel), 2 CH (2 DMX channels) or 3 CH (3 DMX channels). Use the buttons UP and DOWN to
select the desired number of DMX channels. Confirm with the ENTER button.
3 A dot will be flashing when DMX signals are being received.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.
