DMX CONTROL
DMX512 Control
A DMX512 data link is required in order to control the device via DMX. The device provides 3-pin XLR connectors
for DMX connection.
1 Connect the output of your DMX controller to the DMX input DMX IN of the device with a DMX cable.
2 Connect the DMX output DMX OUT of the device to the DMX input of the next unit in the chain. Always connect
one output to the input of the next unit until all units are connected.
3 At the last unit, the DMX cable has to be terminated. Plug the terminator with a 120 Ω resistor between signal
(–) and signal (+) in the DMX output of the last unit.
4 If the cable length exceeds 300 m or the number of DMX devices is greater than 32, it is recommended to
insert a DMX level amplifier to ensure proper data transmission.
Adjusting the DMX start address
The machine reserves two control channels on the DMX controller. To ensure that the control signals are properly
directed to the machine, it must be adjusted to the DMX start address provided for it on the DMX controller. Use
the MENU button to navigate to the menu item Addr and confirm with ENTER. Then use the buttons UP and
DOWN to set the address between 001 and 512. You can now start operating the machine via your DMX
controller.
Note
Please make sure that you do not have any overlapping channels in order to control each device correctly and
independently from any other fixture on the DMX data link. If two, three or more devices are addressed similarly,
they will work similarly.
DMX functions
Channel Value Function
1
000 Spark effect OFF
001-255 Spark effect ON 1-100 %
2
000-020 Warming up function OFF, channel 1 disabled
021-049 No function
050-100 Warming up function ON, channel 1 available
101-149 No function
150-200 Cleaning function (15 seconds), channel 1 disabled
201-255 No function
