Getting Started (Cont.)
Castor wheel assembly
The castor wheels have to be assembled according to the instructions below
using the assembly hardware supplied.
1. Insert a gasket over the screw thread onto the screw shank (A), then insert
the screw with the gasket through the mounting hole of the footrest (B) and
into the screw hole of the castor wheel axle (C). Screw the parts together.
2. To secure the two parts, insert a gasket over the screw tip (D) and tighten
with a nut (E), using a tool (F).
3. Follow the same procedure to secure the other side of the wheel axle to the
footrest (G).
A B
C
D E
F
G
