1918
Adapter
WARNING
Remove the connecting pieces of the plastic adapter com-
pletely before you use one of the supplied adapter!
For the following valves no adapter is required:
Heimeier, Junkers Landy + Gyr, MNG, Honeywell, Brauk-
mann, as these have a thread of M30 x 1.5 mm. The adapt-
ers for Danfoss RAV (pin must be plugged on the valve
tappet) Danfoss RA and Danfoss RAVL are included.
For the following valves you need an adapter:
Herz M28 x 1.5 mm, Comap M28 x 1.5 mm, Vaillant 30.5
mm, Oventrop M30 x 1.0 mm, Meges M38 x 1,5 mmm,
Ondal M38 x 1.5mm, Giacomini 22.6 mm, Rossweiner M33
x 2.0 mm, Markaryd M28 x 1.0 mm, Ista M32 x 1.0 mm,
Vama M28 x 1.0 mm, Pettinaroli M28 x 1.5 mm, T+A M28 x
1.5 mm or Gampper 1,2,6.
If you are not sure which valve you have, see:
www.eurotronic.org/Produkte/Adapter Information.
Here you will find a list of various valves and adapters.
INFO – Adapter
For other fee-based brass adapter types, see:
www.eurotronic.org/shop
For information on the adapters, see the point adapter
or see: www.eurotronic.org/Service/FAQ.
Press the button
MENU
and select with the setting wheel
the menu item
INST. Confirm with OK. While the valve
completely retracts, Comet DECT stands on
PREP. When
this process is finished,
INST is again on the display. Un-
screw the cap nut and remove Comet DECT off the valve.
Technical specifications
Wireless standard DECT ULE
Range: in buildings up to 40 m
System requirement
FRITZ!Box 7490 or 7390
FRITZ!OS from 6:35
2.1.
Dismantling the Comet DECT
