IB70 / IB100 DUAL CONTROL COMPRESSOR
REFRIGERATOR I
NSTRUCTIONS
Operation
Power： The fridge can be powered by DC 12 and 24 Volt using the 12 Volt lead supplied or
with an AC Adaptor the unit can be run off 240V (mains power).
Battery Protection:
Push and hold the button for three seconds and the Battery Voltage will flash. You can
adjust the low voltage cutout to your own needs. The default and recommended voltage is
10.5 Volts.
Cable Length Specification
The DC cables must have a suitable cross-section for their length** (measured from the
battery to the unit), according to this table:
Cable Area
12V Max Cable
Length
24V Max Cable
Length
[mm2]
AWG
[m]
[ft.]
[m]
[ft.]
2.5
14
2.5
8
5
16
4
12
4
13
8
26
6
10
6
20
12
39
10
8
10
33
20
66
**The length is from the battery to the refrigerator.
