Evco S.r.l. • Code 104K214E04 • page 2/6
3.2 Setting the operational setpoint
• ensure the keyboard is not blocked and that no procedures are
running
• press
the LED will flash
• press or within 15 s; also see parameters r1, r2 and r3
• press or do not operate the keypad for 15 s.
It is also possible to set the operational setpoint by means of parameter
SP.
3.3 Setting the configuration parameters
To access the procedure:
• ensure no procedures are running
• press and for 4 s: the display will show “PA”
• press
• press or within 15 s to set “-19”
• press or do not operate the keypad for 15 s
• press and for 4 s: the display will show “SP”.
To select a parameter:
• press or
To select a parameter:
• press
• press or within 15 s
• press or do not operate the keypad for 15 s.
To exit the procedure:
• press and for 4 s or do not operate the keypad for 60 s.
Interrupt the device power supply after altering the param-
eters.
3.4 Resetting configuration parameter default values
• ensure no procedures are running
• press and for 4 s: the display will show “PA”
• press
• press or within 15 s to set “743”
• press or do not operate the keypad for 15 s
• press and for 4 s: the display will show “dEF”
• press
• press or within 15 s to set “149”
• press or do not operate the keypad for 15 s: the display will flash
"dEF" for 4 s, after which the device will exit the proce-
dure
• interrupt the power to the device.
Ensure that the parameter default values are appropriate,
particularly if the probes are PTC type.
4 HACCP
4.1 Introductory comments
The device is capable of storing up to 9 HACCP alarms, after which the
most recent alarm will overwrite the oldest.
The device can furnish the following information:
• the critical value
• the data and time at which the alarm occurred
• the alarm duration (from 1 minute to 99 hours and 59 minutes,
partial if the alarm is ongoing).
CODE ALARM TYPE (AND CRITICAL VALUE)
AL minimum temperature alarm (the minimum temperature
of the cabinet or the minimum temperature detected by
the auxiliary probe during the alarm state)
AH maximum temperature alarm (the maximum temperature
of the cabinet or the maximum temperature detected by
the auxiliary probe during the alarm state)
id microport input alarm (the maximum temperature of the
cabinet during the alarm state); see also parameter i4
PF power failure alarm (the temperature of the cabinet on
restoration of the power supply); see also parameter AA
Warnings:
• the device records minimum temperature alarms and
maximum temperature alarms providing the temperature
associated with the alarm is the cabinet temperature
(parameters A0 and A3 = 0) or the temperature measured
by the auxiliary probe, providing its function is that of
display probe (parameter P4 = 1 and parameters A0 = 2
and A3 = 1)
• in order to avoid repeatedly recording power failure alarms,
disconnect the device power supply while in stand by
mode
• if the duration of a power failure alarm is such as to
cause a clock error, then the device will not provide any
information regarding alarm duration
• no alarms will be recorded if the device is in stand-by
mode.
When the cause of the alarm is resolved, the display returns to normal,
except in the case of a power failure alarm where normal display
function must be restored manually.
To restore the normal display manually:
• press any key.
If parameter u1 is set to 4 (or the service controlled by the fourth output
is the alarm output), then pressing any key will also deactivate the
alarm output.
The HACCP LED provides information relating to the status of the
HACCP alarm memory; please refer to paragraph 6.1.
4.2 Viewing HACCP alarm information
To access the procedure:
• ensure the keyboard is not blocked and that no procedures are
running
• press for 2 s: the display will show the first available label
• press or to select “LS”
• press
the display will show the most recent alarm code, or one
of the codes reported in the table in paragraph 4.1 fol-
lowed by the number "1" (the higher the number follow-
ing the code, the older the alarm).
To select an alarm:
• press
or (to select "AH3" for example).
To display the information relating to the alarm:
• press the HACCP LED will stop flashing and remain on and the
display will show the following information in succes-
sion (for example):
INFO MEANING
8,0 the critical value is 8.0 °C/8 °F
StA the display is about to show the data and time at which the
alarm occurred
y07 the alarm occurred in 2007 (continued ...)
n03 the alarm occurred in the month of march (continued ...)
d26 the alarm occurred on 26 March 2007
h16 the alarm occurred at 16 hours (continued ...)
n30 the alarm occurred at 16:30 hours
dur the display is about to show the alarm duration
h01 the alarm lasted for 1 hour (continued ...)
n15 the alarm lasted for 1 hour and 15 minutes
AH3 the selected alarm
The display shows each piece of information for 1 s.
To exit the information series:
• press the display will show the selected alarm.
To exit the procedure:
• exit the information series
• press or until the display shows the quantity assigned by
parameter P5 or do not operate the keypad for
60 s.
Alternatively:
• exit the information series
• press
If the instrument has stored no alarm, the label “LS” will not be shown.
4.3 Deleting the HACCP alarm list
• ensure the keyboard is not blocked and that no procedures are
running
• press for 2 s: the display will show the first available label
• press or to select “rLS”
• press
• press or within 15 s to set “149”
• press or do not operate the keypad for 15 s: the display will flash
"- - - -" for 4 s and the HACCP LED will be turned off, after
which the device will exit the procedure.
If the instrument has stored no alarm, the label “rLS” will not be shown.
5 COMPRESSOR OPERATION TIME COUNTER
5.1 Introductory comments
The device is capable of recording up to 9,999 hours of compressor
function, after which the number "9999" flashes.
5.2 Displaying the compressor operation time
• ensure the keyboard is not blocked and that no procedures are
running
• press for 2 s: the display will show the first available label
• press or to select “CH”
• press
To exit the procedure:
• press or do not operate the keypad for 60 s
• press or until the display shows the quantity assigned by
parameter P5 or do not operate the keypad for
60 s.
Alternatively:
• press
5.3 Resetting the compressor operation time
• ensure the keyboard is not blocked and that no procedures are
running
• press for 2 s: the display will show the first available label
• press or to select rCH”
• press
• press or within 15 s to set “149”
• press or do not operate the keypad for 15 s: the display will flash
"- - - -" for 4 s, after which the device will exit the procedure.
6 INDICATORS
6.1 Indicators
LED MEANING
compressor LED
if on then the compressor is on
if flashing:
• the operational setpoint is being changed
• compressor protection is ongoing (parameters C0, C1,
C2 and i7)
defrosting LED
if on, defrosting ongoing
if flashing:
• defrosting has been requested, but compressor protec-
tion is ongoing (parameters C0, C1 and C2)
• drip-draining is ongoing (parameter d7)
• refrigerant fluid heating is ongoing (parameter dA)
Evaporator fan LED
if on then the evaporator fan is on
if flashing, then evaporator fan stop is ongoing (parameter
F3)
HACCP HACCP LED
if on, you will have not shown all the information on the
HACCP alarms
if flashing, the instrument will have stored at least one new
HACCP alarm
if off, you will have shown all the information on the HACCP
alarms or you will have cancelled the list of the HACCP
alarms
Maintenance LED
if on, compressor maintenance will be required (param-
eter C10)
alarm LED
if on, an alarm state or an error is ongoing
on/stand-by LED
if on, the device is in stand-by mode
°C degree Celsius LED
if on, the unit of measurement for temperature is degrees
Celsius (parameter P2)
if flashing, then the Energy Saving function is in operation
(parameters r4, i5, HE1 and HE2)
°F degree Fahrenheit LED
if on, the unit of measurement for temperature is degrees
Fahrenheit (parameter P2)
if flashing, then the Energy Saving function is in operation
(parameters r4, i5, HE1 and HE2)
Multifunction LED
parameter u1 is set to 0 (i.e. the service control-
led by the fourth output is the cabinet light)
if on, the cabinet light will have been switched on manu-
ally
if flashing, the cabinet light will have been turned on re-
motely (parameter i0)
parameter u1 is set to 1, 4, 5, 6 or 7
if on, the service controlled by the fourth output will be
turned on
parameter is set to 2 (i.e. the service controlled
by the fourth output is the auxiliary output)
if on, the auxiliary output will have been turned on manu-
ally
if flashing, the auxiliary output will have been turned on
remotely (parameter i5)
parameter u1 is set to 3 (i.e. the service control-
led by the fourth output is compressor 2)
if on, compressor 2 is on
if flashing, compressor 2 delay is ongoing (parameter C9)
CODE MEANING
Loc the key and/or operational setpoint are blocked (param-
eter r3), refer to paragraph 2.11
- - - - the quantity for display is not available (e.g. the probe is
absent)
7 ALARMS
7.1 Alarms
CODE MEANING
AL Minimum temperature alarm (HACCP alarm)
Remedies:
•check the alarm temperature
• check parameters A0, A1 and A2
Main consequences:
• if parameter A0 is set to 0 or if parameter P4 is set to 1 and
parameter A0 is set to 2, the device records the alarms
• if parameter u1 is set to 4, the alarm output will be acti-
vated
AH Maximum temperature alarm (HACCP alarm)
Remedies:
• check the alarm temperature
• check parameters A3, A4 and A5
Main consequences:
• if parameter A3 is set to 0 or if parameter P4 is set to 1 and
parameter A3 is set to 1, the device records the alarms
• if parameter u1 is set to 4, the alarm output will be acti-
vated
id Microport input alarm (HACCP alarm)
Remedies:
• check the causes which activated the input
• check parameters i0, i1 andi4
Main consequences:
• the outcome set by parameter i0
• if parameter i4 is set to 1, the device records the alarms,
providing parameter i2 is not set to -1
• if parameter u1 is set to 4, the alarm output will be acti-
vated
PF Power failure alarm (HACCP alarm)
Remedies:
• check the causes of the power failure
• press any key
Main consequences:
• the device records the alarm; see also parameter AA
• if parameter u1 is set to 4, the alarm output will be acti-
vated; pressing any key will also deactivate the alarm
output
iA Input malfunction alarm (only if parameter P4 is set to 3)
Remedies:
• check the causes which activated the input
To Next Page
