Connect Eve Light Switch
2
• 1: Output (light)
• N: Neutral line
Eve Light Switch requires that a
neutral line is connected. As an
option, the second connection
can be used to loop through
the neutral line for a connected
light, replacing a corresponding
terminal. If the outlet is not
equipped with a neutral line, Eve
Light Switch is incompatible with
this outlet.
• L: Outer conductor / phase
(current-carrying line)
If you‘re not sure which line is
live and which is connected to the
light, just try one. Switching the
input (L) and output (1) will not
damage Eve Light Switch.
Eve Light Switch does not
require a connection to a
protective conductor / ground
wire (PE, usually green yellow).
1x N
2x N
