Mounting Eve Smoke
Position the mounting plate and trace the screw holes. Remove the mounting plate and drill into your
tracings. Secure the mounting plate using the supplied wall plugs and screws.
Upon correct installation, the
Status LED will flash yellow
rapidly, then flash once every
10 seconds to signal that your
Eve Smoke is fully functional
and ready to use.
Applying gentle pressure, press
and turn Eve Smoke in a clock-
wise direction until it locks
in place.
Testing Eve Smoke
• Eve Smoke must be fitted to the mounting plate before testing
• Never test Eve Smoke using an open flame
• Perform at least one test per month, and directly after extended periods away from home
Use the Eve app to conveniently test Eve Smoke at any time. Alternatively, trigger a test alarm by pressing and
holding the Test button until you hear the 2nd sound, then release the button.
Use the Eve app or press the Test button again to deactivate the alarm.
The LED alignment arrow shows you the direction of the Status LED after
installation.
Align Eve Smoke as per the
illustration within the center
of the mounting plate.
6
5
Ring
marker
Test alarm
Red, rapid flash Sound/pause every 1 secondOn
Status LED Emergency light
Sound
(75 dB(A) at 1 m)
