STEP 7
:
INSTALL & CONNECT BATTERY
Once the battery has been fully 1.
charged (see section “Battery Care and
Maintenance” on Page 8), simply slide it
into the rack from the back.
Using your key, lock the battery — this 2.
will help stabilize it when riding and also
provide some anti-theft security. The
lock is located on the left side of the
battery case.
FIG 9. KEY LOCK
FIT aDJusTMenTs luna
Many parts of your new EVELO Electric Bicycle can be
customized for a personalized t.
Seat Adjustment
The seat is easily adjusted up or down by ipping the quick-release lever that clamps
the post into the bike. Note that there is a “minimum insertion line” stamped on the seat
post that must be adhered to for safety’s sake. (If you need your seat to be higher than
permitted with the stock seat post, please contact us.)
The seat can also be moved forward and backward by loosening the single bolt on the
underside of the seat. Since it slides on its rails, there is no need to remove the bolt — just
loosen it, adjust, and rmly re-tighten. Loosening this bolt also lets you change the angle
of the seat up or down a bit. Again, be sure to re-tighten it rmly if you loosen it to change
the seat position in any way.
Stem Adjustment
To adjust the handlebars to a customized height, lift the clamping lever (as you did during
assembly) to access the silver pivot bolt. Loosen that bolt, adjust the height, and re-
tighten the bolt. Next, reposition the handlebars and lower the clamping lever.
Front Shock
Please consult the manual provided by the manufacturer.
Tire Inflation
The tires have a range of recommended ination of 40-65 psi. This range is also indicated
on the sidewall of the tire. Lower pressure will give a softer ride. A higher pressure will
provide a rmer ride, but will give the best range per charge.
