10
ASSEMBLY
quest_manual_final_single.indd 10 09/06/2017 19:55
Step 1
Attach Rear fenders
The Compass is intentionally shipped upside down to facilitate assembly. These instructions
proceed assuming the Compass is inverted, resting on the cargo basket.
1. Remove the six bolts from the frame
near the rear axle and set them aside:
2. Pass the tail light wire OVER the
axle as shown:
3. Loosely screw in one of the bolts:
