Step 4 Attach Rear Wheels
2. The left side wheel engages 3 pins on
the axle flange. Locate those pins and
slide one of the wheels on. Guide the
wheel so that the pins fit into the wheel's
holes.
1. Remove the axle caps and bolts:
IF THE WHEEL ONLY SLIDES ON A SHORT DISTANCE:
The bearing spacer may be interfering. It is in the hub to prevent the wheel bearings from moving.
It can be easily aligned with the axle with a finger, or an object like a pen. Just reposition it as you
move the wheel inward.
