Evenflo Express - Booster Cushion; Removing the Harness System

26 27
Child Requirements
• Weight: 18 to 45.3 kg (40 to 100 lbs)
• Height: 109 to 137 cm (43 to
54 inches) and until the child’s ears
are at the top of the child restraint’s
seat back.
• Age: At least three years old.
• Use only the vehicle’s lap and shoulder belt system when
restraining the child in this booster cushion.
• NEVER use the belt-positioning booster with a lap belt
only. Serious injury or death can occur.
• NEVER use a locking clip with a belt-positioning booster
cushion.
• DO NOT put the shoulder belt behind the child.
• IF YOUR MODEL HAS ARMRESTS:
When using this child restraint as a belt-positioning
booster cushion with the vehicle lap/shoulder belts, you
MUST route the lap portion of the seat belt between the
back of the armrest and seat (see page 29).
• 18 – 45.3 kg (40 – 100 lbs)
AND
• Between 109 and 137 cm (43 and 54 inches)
AND
• Shoulders above harness slots
AND
• Ears below seat back
AND
• At least three years old.
Use WITHOUT 5-pt Harness
Using your Child Restraint as a
Belt-positioning Booster Cushion
Using the Child Restraint as a Belt-positioning Booster Cushion 18 – 45.3 kg (40 – 100 lbs)


➚
Unfasten the buckle tongues from the buckle then press
thumb tab  and release harness anchor .
Turn the harness anchor  sideways and slip it through
the slot in the seat back as shown.
You MUST remove the harness straps BEFORE using
this restraint as a belt-positioning booster cushion.
Before removing the harness, note the harness position
for reassembly. To reinstall the harness system, reverse
the procedure below.
Feed one end of the
shoulder harness assem-
bly through the hole in
the bottom of the seat
shell and up through the
other side as shown.
➚
Removing the Harness System
1
2
To remove the crotch strap, turn the harness anchor
sideways and push it up through the hole in the seat
shell and remove it from the seat pad.
➚
3
WARNING
WARNING
