No more than
13 mm (1/2”)
Thread the locking clip onto the seat belts as shown. The
locking clip must be placed within 13 mm (1/2 inch) of
the buckle tongue. Re-buckle the seat belt buckle.
Check your work. Make certain the belts are
tight. If you can move the child restraint more than
25 mm (1 inch) forward or side-to-side at the belt
path , the belts are not tight enough. You will
need to try again, or find another location for your
child restraint.
→
→
• DO NOT use this child restraint if it moves more
than 25 mm (1 inch) forward or side-to-side at
the belt path. Serious injury or death may result
from poor installation. Move the child restraint to
another seating location, or try to tighten the seat
belt again.
• DO NOT allow the vehicle seat belt release button
to touch the child restraint. Accidental contact may
cause the seat belt to release. If necessary, turn the
vehicle seat belt release button away from the child
restraint or move the child restraint to a different
location.
3
4
14 15
Remove the locking clip from
the back of the child restraint.
For use with lap/shoulder combination seat belts with a
free-sliding buckle tongue.
•
NEVER
use a locking clip when using this child restraint
as a belt-positioning booster cushion without the
5-point harness). Serious injury could occur.
• Remove locking clip from vehicle seat belt when not
used with a child restraint, or the vehicle seat belt will
not properly restrain an adult or child. Serious injury
could occur.
See pages 11 – 13 for child restraint installation. Using
your full weight, press down on the child restraint as
you pull on the shoulder belt to remove all slack. Hold
the lap and shoulder belts together just behind the
free-sliding buckle tongue . Unbuckle the seat belt.
Using the Locking Clip
1
2
Using the Child Restraint with the 5-point Harness: 9 – 21.3 kg (20 – 47 lbs) Seat Belt Installation
WARNING
WARNING
To Next Page
