Assembling the ExerSaucer
Assembling the ExerSaucer
9. Press assembled seat M down firmly onto the top of the tray
N until it snaps into place and spins freely.
11. Insert a strap P through a strap slot Q in the tray O. Pull the strap completely through the tray making sure the strap
anchor R lies flat against the bottom of the tray, as shown. Repeat for the other two straps.
Attaching the Toys
WARNING
To prevent injury, make sure all three strap anchors are completely
inserted and resting against the bottom of the tray.
8. Turn seat ring G right side up.
Align the two triangles on the back
of the seat ring with the two
triangles on the label on the seat
pad J.
Snap the plastic tabs K on the pad
over the pegs L on the seat ring.
Continue this process until all tabs
are attached to all pegs.
L
L
K
K
Triangles
J
M
M
N
O
G
10. Lean the tray assembly O against one of the pylons,
as shown.
P
P
Q
O
R
+
+
+
–
–
–
3 “AAA” Batteries
+
+
+
–
–
–
3 “AAA” Batteries
