Evenflo REVOLVE360 User Manual

11
Child Requirements
Rear-Facing Mode
OPTIONAL: To ensure a better t for
smaller infants, the Body Pillow (pg. 47)
and/or Head Pillow (pg. 48) may be used
in REAR-FACING mode ONLY.
1.9 - 9kg (4 - 20 lbs)
Lower Connectors/UAS
Lap/Shoulder Belt Lap Belt
Always use tether strap in rear-facing installation.
Ball must be in proper
zone for child size:
Vehicle MUST be on
level ground.
25809042 10/20
9 - 18kg (20 - 40 lbs)
Do not install by
this method for a
child weighing
more than
15.9 kg
(35 lbs).
LEVEL INDICATOR
REAR-FACING ONLY
1.9 - 18 kg (4 - 40 lbs)
44 - 101 cm (17 - 40 in)
REAR-FACING
For REAR-FACING installation, Recline
Ball should be in correct zone for child
size:
• White Zone: 1.9 - 9 kg (4 - 20 lbs)
• Black Zone: 9 - 18 kg (20 - 40 lbs)

Evenflo REVOLVE360 Specifications

General

Type	Convertible Car Seat
Rotation	360-degree rotation
Rear-Facing Weight Capacity	4-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Harness	5-point harness
Headrest Positions	10
Safety Standards	FMVSS 213
Side Impact Protection	Yes
Machine Washable Cover	Yes
Installation	LATCH or seat belt
