Evenflo REVOLVE360 User Manual

46
Car Seat Features
Cup Holders
Cup holders are removable and
dishwasher safe (top rack only). To
remove, rotate the cup holder toward the
interior of the Seat Shell and pull up to
release.
To re-install:
1. Align tabs on base of cup holder
with slots on Seat Shell and push
down into slots.
2. Rotate cup holder toward the
outside of the Seat Shell until
locked.
3. Pull up vertically to ensure proper
installation.
NOTE: The bottom of each cup holder
is labeled "L" or "R" for left or right-side
use.

Evenflo REVOLVE360 Specifications

General

Type	Convertible Car Seat
Rotation	360-degree rotation
Rear-Facing Weight Capacity	4-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Harness	5-point harness
Headrest Positions	10
Safety Standards	FMVSS 213
Side Impact Protection	Yes
Machine Washable Cover	Yes
Installation	LATCH or seat belt
