Using Batteries
If you plan to use batteries, lift tab on battery door A and insert six alkaline
“AA” batteries B (not included). For best performance, brand name non-
rechargeable batteries are recommended. Replace battery door.
• DO NOT mix old and new batteries.
• DO NOT mix battery types; leakage, explosion and/or fire could occur.
• Remove batteries before putting product into storage.
WARNING
A
B
Low Battery Indication
When batteries are low, the first suction level indicator C will blink, but the
pump will still be usable.
Once battery level is too low to pump, the pump will stop and not turn on
until the batteries are replaced or the AC adapter is used. During this time
the first suction level indicator C will blink, but the pump will not turn on.
Single Versus Double Pumping
Attaching Flange Assembly to Pump Unit
Insert tubing adapter
A into the port B
on the side of the pump unit C.
Note: To minimize damage to the pump
unit, always operate with a flange assembly
attached.
Power Options
This pump can be powered by either 6 “AA” batteries or the supplied
Evenflo AC adapter.
Note: When batteries are first installed or when AC adapter is first plugged in,
the pump unit will briefly turn on then off; this is normal.
To Pump One Breast at a Time
Cap one side of the tubing adapter with
the attached cap
A. Connect one tube B
to the other side.
Note: The open side must be completely
capped to ensure proper suction.
To Pump Both Breasts at the Same Time
Ensure that both tubes B are properly
connected to the tubing adapter A.
The tubing adapter can be used to pump with one or both flanges.
A
C
B
B
A
B
A
C
