The following things should be checked before starting the dishwasher.
Start of Dishwasher
1 Whether the dishwasher is level and fixed in to position.
2 Whether the inlet valve is opened.
3 Drain hose connected has the plug in waste tee been opened for drainage
4 Whether there is leakage at the hose connections
5 Whether the power cord is connected and power switched on.
6 Whether the inlet and drain hoses are kinked (as per page 4).
7 All packing materials and printings should be taken out from the dishwasher.
8 Can the spray arms rotate freely
If the sink is 100cm higher from the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable
container that is held outside and lower than the sink.
How to Drain Excess Water From Hoses
Water Outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water inlet hose is not kinked or squashed.
Syphon Connection
Extension Hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must be no longer than 4 metres; otherwise the cleaning effect of the dishwasher could be reduced.
The waste connection must be at a height of between 40 cm (minimum) and 100 cm (maximum)
from the bottom of the dish. The water drain hose should be fixed by a hose clip. The free end of
the hose must not be immersed in water.
6
Drain hose Connection
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to
avoid bending or crimping. Use the special plastic support that comes with the appliance. The free end of the hose
must be at a height between 40 and 100cm and must not be immersed in water.
Max 1000mm
Min 400mm
FRONT VIEW
Inlet pipe connectorDrain pipe connector
POWER OUTLET
SINK
DISHWASHER
Min 100mm
WARNING!
DO NOT BEND IN ANY WAY !
