Everfit TFK 430 - Page 13

20
C7 Drive belt
1
C20 Magnetic ring
1
C8 Power switch 1
C21 Inductor 1
C9 Controller 1
C22 Filter 1
C10 Button on left handrail
1
C27 Single cord (black)
2
C11 Button on right handrail
1
D. Hardware parts
No. Description QTY No. Description QTY
D1 Screw driver 13-15-17 1 D29 Hex round head bolt M6X45 1
D3
Allen wrench T5
1 D30
Hex round head bolt M6X60
2
D9
Round hex bolt M10X30
1 D31 Hex round head bolt M8X20 4
D10
Round hex bolt M10*45
4
D35
Hex round head bolt M8X80
1
D11
Round hex bolt M10*50
3
D36
Cross head bolt M6X25
2
D13 Round hex bolt M8X15 4
D43
Cross head bolt M4X20
2
D14
Round hex bolt M8X30
1 D45
Cross head bolt M5X15
7
D15 Round hex bolt M8X40
4
D46 Cross head bolt M5X20 2
D16
Round hex bolt M8X45
7 D47
Cross self-tapping bolt
ST4.2X16, washer
13
D17
Inner star washer M 8
8 D48
Cross self-tapping bolt
ST4.2X19, washer
2
D18
Nylon nut M10
8
D52
Cross head bolt ST4.2X16
19
D20 Nylon nut M8 8 D57
Cross self-tapping bolt
ST4.2X25
4
D21
Flat washer M 10
8
D60
Cross head bolt M6X20
6
D23
Flat washer M 8
15 D61
Cross self-tapping bolt
ST4.2X19
2
D24 Spring washer M5
1
D82 Cross head bolt M4X12 4
D25
Spring washer M8
4
