Everfit TFK 430 - Assembly Instruction

4
WHEN YOU OPEN THE CARTON, YOU WILL FIND THE BELOW SPARE PARTS:
STEP 1: Take out and prepare the below parts
Main frame 1 set D17 Inner star washer
M8 8 PCs
D13 Round hex bolt
M8*15 4 PCs
C13 Safety pad 1
PC
D3 Allen wrench
5MM, 1 PC
B18 Silicon 1 PC B49 Water bottle cup
holder 2 PCs
D16 Round hex bolt
M8*45 4 PCs
B11L
Left side cover
1 PC
B11R Right side cover
1 PC
D48 Cross self-tapping
bolt ST4.2*19, washer
2 PCs
D1 Screw driver 1
PC
STEP 2: According to the following steps to lift up the uprights.
Assemb
ly
instruction
