EAN850A
58
5. SPECIFICATIONS
CAMERA
Pickup Device 1/3" Sony Super HAD Interlaced CCD, PoleStar solution
Pixel Effective NTSC: 768 (H) x 494 (V); PAL: 752 (H) x 582 (V)
Sensitivity 0.002 Lux (SENS-UP X128); 0.25 Lux / F=1.2
Day & Night True Day/Night with IR cut filter
Lens Optional C/CS mount, manual / DD control supported
Video Output BNC socket, composite 1 V p-p / 75Ω
Video Output Resolution 560 TVL
VIDEO STREAMING
Video Compression H.264/MPEG-4/M-JPEG
Video Resolution D1, VGA, CIF, QVGA, QCIF
Video Quality 8 levels adjustable
Frame Rate Up to 30fps
AUDIO
Microphone Built-in omni-directional microphone (not available for U.S. region)
Audio Input 3.5 mm stereo socket, sensitivity 1 Vrms
Audio Output 3.5 mm stereo socket, sensitivity 1 Vrms at load of 10KOhm and 50pf.
Compression Method IMA ADPCM (Pulse Code Modulation)
Operation Mode 2 way audio
NETWORK
Interface 10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Support MDI/MDI-X auto crossover function
Supported Protocols HTTP, TCP / IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Bandwidth Control Min. 64 kbps adjustable
Max. Client Limit 32 simultaneous clients
ALARM
Alarm Input 1 x input for dry contacts, Normal Open / Normal Closed adjustable
Alarm Output 1 x dry relay contact, Normal Open / Normal Closed adjustable,
70 VDC / 200 mA max
SERIAL INTERFACE
