4. OSD Structure
Main Sub Menu Sub Menu
SETUP
EXPOSURE
BRIGHTNESS 0 ~ 20
SHUTTER MODE AUTO, MANUAL
SHUTTER
SPEED
1/30(25), 1/60(50), 1/120(100), 1/250, 1/700, 1/1K,
1/1.6K, 1/2.5K, 1/5K, 1/7K, 1/10K, 1/30K.
DSS
(Digital Slow Shutter)
OFF, X2, X3, X4.
AGC MAX 0 ~ 23dB
INITIAL
RETURN
WHITE BALANCE
WB MODE AUTO / PUSH LOCK / MANUAL
CHROMA 0 ~ 20
KELVIN LOW, MIDDLE, HIGH
RED GAIN 0 ~ 20
BLUE GAIN 0 ~ 20
PUSH AUTO -
INITIAL
RETURN
BLC
MODE OFF, BLC
BLC OSD OFF, ON
BLC X - POSITION 0 ~ 20
BLC Y - POSITION 0 ~ 20
BLC X - SIZE 0 ~ 20
BLC Y - SIZE 0 ~ 20
INITIAL
RETURN
DAY & NIGHT
D&N MODE AUTO, COLOR, BW
DWELL TIME 1sec ~ 10sec
AGC THRS 0 ~ 20
MARGIN 0 ~ 20
INITIAL
RETURN
SHARPNESS 0 ~ 10
MIRROR OFF, ON
FLIP OFF, ON
DZOOM(Digital Zoom) 1X ~ 20X
SHADING (LSC) OFF, ON
HLMASK (HSBLC) OFF,ON
HLMASK LEVEL 0 ~ 20
HLMASK COLOR
WHITE, YELLOW, CYAN, GREEN
MAGENTA, RED, BLUE, BLACK
INITIAL
RETURN
DNR OFF, LOW, MIDDLE, HIGH
INITIAL
RETURN
