10
1.4 Dimensions
Inches:
MOUNTING HOLE (Top/Bottom)
(1/4"-20 UNC, Depth 0.17")
MOUNTING HOLE (Top/Bottom)
(1/4"-20 UNC, Depth 0.17")
2.95"
Ø1.77"
3.81"
Ø2.36"
0.1"-Ø0.14"
1.63"
1.41"
3.45"
