1.3 Speci cations
Pickup Device
1/3” Panasonic 2.1 Megapixel Color Progressive CMOS sensor
Image Pixels
1920(H)x1080(V) with 2.75μx 2.75μ pixel size
HDcctv Image Area Dimensions
5.28mm (H) x 2.97 mm(W); ø 6.06 mm area diagonal
Sensitivity
0.1 lux/F1.2 (DSS OFF)
S/N Ratio More than 50dB
Video Format Main Output HDcctv
Video Resolution/Mode Main Output
Field Select 1080p30/25, 720p60/50
Main Output Connector BNC-F
Video Format Test Output
NTSC/PAL Selectable
Test Output Connector
Pin connector on board; adapter to BNC supplied
Lens Type
2.45mm Fixed Focal Length
FOV Angle
94°Horizontal
Shutter Speed Auto / Manual Selectable
OSD Yes (5-axis joystick control)
D/N Mode
Auto, Color, B/W (Electronic D/N)
Exposure Control
Automatic Electronic Shutter
DSS Low light boost 2X, 3X, 4X
Lens Shading Compensation
On / Off
Auto Gain Control
Variable 0~23dB (23bD=200x)
White Balance ATW/Push/Manual/Outdoor/Indoor
DNR Low / Medium / High
HSBLC On / Off
Digital Zoom 1X ~20X
Power Source & Consumption
DC12V (+/-10%) @ 160mA
Image Flip Off/V Flip/H Flip/H+V Flip (Rotate)
Programable Privacy Zones 30 areas independently adjustable for size, location, color
Weight
136.1g/408oz (Camera Only; Mount adds 113.4g/4oz)
Dimensions
Body: 86.7mm/3.41"(L) x Ø44mm/Ø1.77" Diameter(W)
Mount: Ø60mm/Ø2.36" Diameter(W)
[Adds 97.6mm/3.84" max to height]
Operating Temperature -10°C~50°C ; 14°F~122°F
Operating Humidity 20%~80% humidity, non-condensing
Certi cations FCC/CE
