SPECIFICATIONS
Camera
Model
ECMD200
Image Pick-up Device
SONY 1/3’’ Super HAD II Color CCD
Effective Picture Elements
NTSC: 768*494
Horizontal Resolution
600 TV lines
Minimum Illumination
0.05LUX @ F2.0
S/N Ratio
More than 52 dB
Auto Electronic Shutter
NTSC:1/60s~1/100,000s, PAL:1/50s~1/110,000s
Gamma Characteristic
0.45
Lens Furnished
Pinhole lens 3.7mm / F2.0
Gain Control Automatic
White Balance ATW (2,000°K~10,500°K)
Digital Wide Dynamic Range
DWDR ON
2D Noise Reduction
2DNR ON
Synchronous System
Internal
Video Output
BNC-F; 1 V p-p Composite Video / 75 ohm
Operating Temperature
-10°C to 50°C (14°F to 122°F)
Humidity
20%~ 80% non-condensing
Power Requirements (camera
only)
12VDC regulated; 100mA
PIR Motion Detector
PIR Detection Angle Horizontal = 100° / Vertical = 45°
PIR Detection Range 10m
PIR N.C/N.O Relay Output 2A @ 24 AC/DC
PIR N.C/N.O Alarm Time Adjustable from 2 to 40 sec.
Case Open Tamper Switch
Built-in switch; trips alarm relay once if PIR case is opened.
Relay operation on switch activation is same as if a PIR
motion alarm is detected: single relay event as per VR2/J4
settings. This is NOT a separate ‘day zone’ or ’24 hour
zone’ type independent/continuous tamper output.
Power Supply
Camera)
DC 12V; Standby current: 1mA; Working current: 25mA
Overall Mechanical
Dimensions 4.72 x 2.76 x 1.89 inches
Weight 130 g / 0.29 lbs
