SPECIFICATIONS
Pickup Device 1/3” SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System NTSC: 525 TV lines, 60 fields/sec; PAL: 625 TV lines, 50 fields/sec.
Picture Element
768 x 494 (NTSC); 752 x 582 (PAL)
Horizontal Resolution 520 TV Lines
Sensitivity
0 Lux (IR LED on)
0.4 Lux/F=1.2 (AGC ON)
Day/Night Type
True Day/night with ICR module
S/N Ratio Over 48 dB (AGC off)
Electronic Shutter 1/50 (1/60) ~ 1/100,000
Lens Type
Vari-focal lens, DC Auto Iris
f=2.8~10mm/f=9~22mm
Iris Level
Adjustable
Auto Gain Control
ON
Back Light Comp. ON
Auto White Balance ON
Gamma Correction 0.45
Video Output 1. BNC 1.0Vp-p, 75 ohm
2. Additional testing video output 1.0Vp-p, 75ohm
Sync. Mode Internal Sync.
Power Source 12VDC/24VAC
Power Consumption 12VDC: 6W max.; 24VAC: 6.5W max.
Dimensions 141 mm (O.D.) x 128? mm (H)/ 5.6” (O.D.) x 5.1 “(H)
Weight 0.66 kg, 1.45 lbs
Operating Temperature 0°C~40°C ; 32°F~104°F (20%~80% Humidity)
IR Distance 20M/66 feet
IR Wavelength 850nm
IR LED Lifespan 20,000 hours
Certifications CE/FCC
