4. SPECIFICATIONS
EMW300
EMW330T
Pickup Device
1/3" SONY Super HAD CCD
Video Format
NTSC and PAL models available
Scanning System
NTSC: 525TV lines, 60 fields/sec; PAL: 625 TV lines, 50
field/sec
Picture Elements
768 x 494(NTSC); 752 X 582 (PAL)
Horizontal Resolution
520 TVL
Sensitivity
0.4 Lux / F=1.2(IR OFF); 0 Lux (IR ON)
S/N Ratio
Over 48 dB (AGC off)
Electronic Shutter
1/50(1/60) ~ 1/100,000
Video Outputs
BNC 1.0Vp-p, 75ohm; video test port
Gamma Correction
0.45
Lens Type
Fixed focal length
f=3.6, 4.3, 6, 8, 12mm
(3.6mm standard)
Vari-Focal Lens,
V3: f=2.9~10mm/F=1.2,
Back Light Comp.
Yes (ON)
Auto Gain control
Yes (ON)
Auto White Balance
Yes (2500

K~9000

K)
Sync. Mode
Internal sync
Day/Night
Electronic
Auto; IR Cut Removable
Day/Night Detection
Visible light sensor
Built-in Heater
Yes
IR LEDS
40 emitters in two arrays
IR LED Lifespan
20,000 hours nominal
IR Distance
50 feet
IR Wavelength
850nm
Weather Proof
IP67
Vandal Resistant
Yes
Power source
12VDC
Power consumption
4.8W max at 12VDC (Heater ON & IR LED ON)
Operating Temperature
-40°C~60°C, -40°F~140°F
Dimensions WxDxH
105 x 140 x 65mm
Weight
600g
Mounting Options
Side/Rear/Wall/Ceiling mounting options, no bracket
required
Camera Angle
Can be rotated 360º on axis in 90º increments to fit
mounting position
Viewing Direction
Dual-Position
Single-Position
