TSC: 525 TV lines, 60 fields/sec.
PAL: 625 TV lines, 50 fields/sec.
Picture Elements 510 x 492 (NTSC); 500 x 582 (PAL)
Horizontal Resolution 380 TVL
Sensitivity 0.3 Lux /F=1.2
S/N Ratio Over 48dB(AGC Off)
Electronic Shutter 1/50(1/60)~1/100,000
Lens
Vari-Focal or Fixed Lens
Video Output BNC 1.0Vp-p 75ohm
Back Light Comp.. On/Off switch
Auto Gain Control On/Off switch
Flickerless On/Off switch
Auto White Balance Auto
Auto IRIS DC-Drive
Gamma Correction 0.45
Sync. Mode Internal Sync.
Power Source Two types:
12VDC/24VAC
12VDC only
Power Consumption 12VDC:3W max.
24VAC: 1.5W max
Video Output Connector
BNC output x 1
2.5mm Lock x 1
AC 24V Power Connector + Video
2.5mm x 2-pin(for DC jack)
2.0mm x 2-pin(for BNC)
DC 12V Power Connector + Video 1.25mm x 4-pin, (1BNC, DC jack)
Weight 0.3 kg ; 0.66 lbs
Dimension 110mm(W)x 125(H)/ 4.33”(W) x4.92”(H)
Pendent Tube Diameter: 26mm/1.06”
Operating Temperature 0~50 ; 32°F~122°F (20%~80% Humidity)
Certifications CE, FCC
