1-Rapid burner
2-Semi-rapid burner
3-Auxiliary burner
4-Command panel
5-Oven handle
6-Top plate
7-Top lid (glass or metal)
8-Oven door
9-Dish warmer Drawer
DESCRIPTION OF THE OVEN and CONTROL PANELS
1
2
3
4
5
66
7
8
9
USING COOKER SECTION
Using Gas Burners:
Closed
Fully open
Half open
1.In order to obtain maximum output, be careful that the saucepan which
will be used should be flat bottomed, and use the saucepans with
dimensions given herein above.
2.The valves controlling the gas cookers have special security mechanism.
In order to light the cooker;
Always press on the switch forward and bring it to flame symbol by turning
counterclockwise. All of the lighters shall operate and the cooker you
controlled shall light only. Keep the switch pressed until ignition is
performed. Press on the lighter button and turn the knob counter
clockwise.
GB
10
