Reduced Flame Gas Cock Adjustment:
In order to adjust your oven to the gas type, make the adjustment for
reduced flame carefully by turning with a small screwdriver as shown
below on the screw in the middle of the gas cocks as well as nozzle
changes.
For oven burners:
1.Please remove nut from on nozzle body
with nutdriver and disconnect gas pipe
from body as Figure-6 and 7.
2.Please remove nozzle body and burner
from cavity as Figure -8/9 and remove nozzle from injector body (Figure-
10/11) and change. Than re-install nozzle body and burner on cavity by
screws.
2.5 Turns Counterclockwise
4,5 Turns Counterclockwise
GB
6
