BURNER INJECTOR VALUES ACCORDING TO THE GAS
TYPE
Wok Burner
Rapid Burner
Semi Rapid Burner
Auxiliary Burner
Oven Burner
Grill Burner
Injector Ø mm
Injector Ø mm
Injector Ø mm
Injector Ø mm
Injector Ø mm
Injector Ø mm
0,96 1,30 1,40
NG
G25/25mbar
NG
G20/20mbar
LPG G30/28-
30mbar
0,85 1,15 1,20
0,65 0,97 0,95
0,50 0,72 0,70
0,70 0,97 0,95
0,60/0,65 0,95 0,92/0,95
Power kW
Power kW
Power kW
Power kW
Power kW
Power kW
3,60 3,35 3,66
3,00 2,77 3,00
1,78 1,78 1,61
0,88 0,99 0,88
2,16/2,22 1,83/2,00 1,72/1,70
1,50/1,72 1,78/1,85 1,50/1,60
Consuption Gr/h,m³/h
Consuption Gr/h,m³/h
Consuption Gr/h,m³/h
Consuption Gr/h,m³/h
Consuption Gr/h,m³/h
Consuption Gr/h,m³/h
284 0,3 0,365
286 0,253 0,326
140 0,167 0,174
70 0,092 0,094
170/175 0,178/0,179 0,183/0,178
118/135 0,162/0,169 0,162/0,173
Supply Voltage
1000 WHot Plate 145 mm
Hot Plate 180 mm
Hot Plate rapid 145 mm
Hot Plate rapid 180 mm
1500 W
1500 W
2000 W
220V-240V AC,50-60Hz (Or 230V400V AC,50-60
Hz)
5
Nozzle change operation:1. Please use driver with special head for
removed and install nozzle as figure-1 2. Please remove nozzle (Figure
-2) from burner with special nozzle driver and install new nozzle
(Figure -3)
Fgure-1 Fgure-2 Fgure-3
