Page 27
HIGH FIDELITY MUSIC STREAMER
Notes：
*Two sets of RCA and XLR connectors can output separately or simultaneously. It is
recommended to choose XLR in priority for noise suppression and signal completeness.
*XLR and RCA separate outputs are available to be selected to minimize the possibility of
signal interference caused by simultaneous RCA and XLR outputs. The separate output mode
supports better audio indicators and sound quality.
Use a USB-A to Type-C cable to connect this device with PC, playback devices and mobile
phones with a USB audio output. Go to "Settings > Source > USB-C In".
USB Type C Input
USB audio data cable
PC/player
USB Type-C/Lightning
OTG audio cable
Mobile
Polarity Diagram
+
-
GND
