EVGA 450B3 - Cable Configurations: 750 W-850 W Models; 750 W B3 Cable Details; 850 W B3 Cable Details

5
English
750B3 Cable Configuration
850B3 Cable Configuration
MB
CPU
VGA1
VGA2
SATA1
SATA2
PERIF
FDD
1 x ATX (20+4)-Pin
1 x EPS/ATX12V 8(4+4)-Pin
2 x PCI-E 8(6+2)-Pin x 2
2 x SATA 5-Pin x 3
1 x Molex 4-Pin x 3
1 x Molex to FDD Adapter
Modular Connector Cables
Black
MB
CPU
VGA1
VGA2
VGA3
SATA1
SATA2
SATA3
PERIF
FDD
1 x ATX (20+4)-Pin
1 x EPS/ATX12V 8(4+4)-Pin
3 x PCI-E 8(6+2)-Pin x 2
3 x SATA 5-Pin x 3
1 x Molex 4-Pin x 3
1 x Molex to FDD Adapter
Modular Connector Cables
Black
450W / 550W / 650W / 750W / 850W BRONZE
Power Supply User Manual
Dimensions: 85mm (H) x 150mm (W) x 160mm (L)
Over Voltage Protection, Under Voltage Protection, Short Circuit Protection,
Over Power Protection, Over Current Protection, Over Temperature Protection.
