EVGA 550 BP - Technical Specifications

05
550 / 650 / 750 BP Specifications
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 7-4A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
20A 20A 45.8A 0.3A 3A
120W 550W
3.6W
15W
550W
550 BP
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 8-4A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
20A 20A 54.2A 0.3A 3A
120W 650W
3.6W 15W
650W
650 BP
AC Input
DC Output
MAX output, A
Combined, W
Output power, P
cont
100-240V~, 10-5A, 60/50Hz
+5V
+3.3V +12V -12V +5Vsb
20A 20A 62.5A 0.3A 3A
120W
750W
3.6W 15W
750W
750 BP
Protection: Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection (SCP),
Over Power Protection (OPP), Over Current Protection (OCP), Over Temperature Protection (OTP).
