1000W / 1300W GOLD Power Supply User Manual 1000W / 1300W GOLD Power Supply User Manual
EVGA
SuperNOVA 1000W GOLD
+50°C ambient @ full load
AC Input
100-240 VAC 15A, 60 / 50 Hz
DC Output +5V +3.3V +12V -12V +5Vsb
MAX output, A
24 24 83.3 0.5 3.0
Combined, W
120 999.6
6.0 15
Output power,
Pcont
1000W @ +50°C
Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Over Power Protection,
Over Current Protection.
Dimensions: 85mm (H) x 150mm (W) x 200mm (L)
SuperNOVA 1000G2 Cable Configuration
SuperNOVA 1000G2 Specifications
Modular Connector Cables Cable Color
MB 1x ATX 24 pin
Black
CPU1
2x EPS12V 4+4 pin
CPU2
VGA1
4x PCI-E 6+2 pin
VGA2
VGA3
VGA4
VGA5
2x PCI-E 6+2 pin + 6 pin
VGA6
SATA1
2x SATA 5 pin x3
SATA2
SATA3
2x SATA 5 pin x2
SATA4
PERIF1 1x Molex 4 pin x3
PERIF2 1x Molex 4 pin x2 + 1 Floppy
EVGA
SuperNOVA 1300W GOLD
+50°C ambient @ full load
AC Input
100-240 VAC 15A, 60 / 50 Hz
DC Output +5V +3.3V +12V -12V +5Vsb
MAX output, A
24 24 108.3 0.5 3.0
Combined, W
120 1299.6
6.0 15
Output power,
Pcont
1000W @ +50°C
Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Over Power Protection,
Over Current Protection.
Dimensions: 85mm (H) x 150mm (W) x 200mm (L)
SuperNOVA 1300G2 Cable Configuration
SuperNOVA 1300G2 Specifications
Modular Connector Cables Cable Color
MB 1x ATX 24 pin
Black
CPU1
2x EPS12V 4+4 pin
CPU2
VGA1
4x PCI-E 6+2 pin
VGA2
VGA3
VGA4
VGA5
2x PCI-E 6+2 pin + 6 pin
VGA6
SATA1
4x SATA 5 pin x3
SATA2
SATA3
SATA4
PERIF1 1x Molex 4 pin x3
PERIF2 1x Molex 4 pin x2 + 1 Floppy
