EVGA SuperNOVA 1600P2 User Manual

1600W PLATINUM Netzteil Bedienungsanleitung1600W PLATINUM Power Supply User Manual
Einführung.......................................................................................................8
Sicherheit........................................................................................................8
Lieferumfang...................................................................................................8
Merkmale.........................................................................................................9
Installation.......................................................................................................9
Häufige Fragen..............................................................................................11
SuperNOVA 1600P2 Kabelkonfiguration......................................................12
SuperNOVA 1600P2 Spezifikationen............................................................12
Inhalt
Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Over Power Protection,
Over Current Protection, Over Temperature Protection.
Dimensions: 85mm (H) x 150mm (W) x 220mm (L)
SuperNOVA 1600P2 Cable Configuration
SuperNOVA 1600P2 Specifications
EVGA
SuperNOVA 1600W PLATINUM
+50°C ambient @ full load
AC Input
115-240 VAC, 17-10A, 60/50 Hz
DC Output +5V +3.3V +12V -12V +5Vsb
MAX output, A
24 24 133.3 0.5 3
Combined, W
120 1599.6
6 15
Output power,
Pcont
1600W @ +50°C
Modular Connector Cables Cable Color
MB 1x ATX 24 pin
Black
CPU1
2x EPS12V 4+4 pin
CPU2
VGA1
4x PCI-E 6+2 pin
VGA2
VGA3
VGA4
VGA5
5x PCI-E 6+2 pin + 6 pin
VGA6
VGA7
VGA8
VGA9
SATA1
3x 4 SATA 5 pinSATA2
SATA3
PERIF 1x 3 Molex 4 pin
1x 2 Molex 4 pin + 2 SATA 5pin
PERIF/SATA
FDD
2x 4-Pin Floppy Adapter
DeutschEnglish
6 7

EVGA SuperNOVA 1600P2 Specifications

General

Brand	EVGA
Model	SuperNOVA 1600P2
Category	Power Supply
Language	English
