EVGA X79 DARK - Motherboard Component Identification Key

12
1. CPU Socket 2011
13. Debug LED
25. PCI-E Slot 4x
2. Intel X79 Southbridge
14. USB 2.0 Headers
26. Front Panel Audio Connector
3. CPU Fan Header
15. USB 3.0 Headers
27. S/PDIF Out
4. DDR3 Memory DIMM Slots 1-8
16. CMOS Battery
28. EVGauge
5. 24-pin ATX power connector
17. Unused
29. Back Panel Connectors (Figure 2)
6. Fan Headers
18. CMOS Reset Button
30. 8 pin EPS Connector
7. PCI-E Disable Dipswitches
19. Power Button
31. Supplemental PCI-E 6pin Power
8. Intel Sata 6G/3G Ports
20. Reset Button
32. Removable BIOS Chip
9. Intel Sata 3G Ports
21. PC Speaker
33. GPU Link
10. Marvell Sata 6G Ports
22. PCI-E Slot 16x/8x
34. Probe It Header
11. ECP Header
23. PCI-E Slot 8x
35 BIOS Selector Switch
12. Front Panel Connectors
24. PCI-E Slot 8x/4x
